SPINE Documentation
Scalable Particle Imaging with Neural Embeddings (SPINE) is a machine-learning reconstruction toolkit for particle imaging detectors, developed primarily for Liquid Argon Time Projection Chambers (LArTPCs). It combines configuration-driven I/O, deep neural network models, object construction, post-processing, analysis, and visualization into a single reconstruction workflow. The schematic below breaks down the full end-to-end reconstruction flow.
For full reconstruction, training, and inference workflows, SPINE is intended to run from the published SPINE container image released alongside each SPINE version. Use the release-tagged image ghcr.io/deeplearnphysics/spine:<release> when reproducibility matters. When in doubt, use ghcr.io/deeplearnphysics/spine:latest or omit the tag entirely, which is equivalent in Docker-style image references. Docker is the usual path on local machines; Apptainer or Singularity is the usual path on HPC systems. A local pip installation is most appropriate when you only need post-processing, analysis, visualization, or lightweight data inspection.
The package is organized around the spine.driver.Driver pipeline:
load detector inputs and labels
run neural network inference or training
unwrap batched outputs
construct fragments, particles, and interactions
apply post-processing and detector matching
run analysis scripts and write results
Getting Started
The landing page should stay short and decision-oriented. The detailed setup and workflow instructions live in the dedicated guides linked below.
Installation
For complete SPINE workflows, start from the released SPINE container image:
# Equivalent to omitting the tag entirely
docker pull ghcr.io/deeplearnphysics/spine:latest
# Use an explicit release tag when you want a pinned runtime
docker pull ghcr.io/deeplearnphysics/spine:<release>
On HPC systems, pull the same released image through Apptainer or Singularity:
# Equivalent to omitting the tag entirely in the Docker image reference
apptainer pull spine_latest.sif docker://ghcr.io/deeplearnphysics/spine:latest
# Or pin to a specific release
apptainer pull spine_<release>.sif docker://ghcr.io/deeplearnphysics/spine:<release>
For local pip installs, development workflows, and the full runtime discussion, see Installation.
For lightweight data inspection and analysis, install the core package directly:
python -m pip install spine
Add the visualization dependencies if you want to use spine.vis:
python -m pip install "spine[viz]"
Quick Start
The quickest local workflow is to inspect an HDF5 file previously produced by
SPINE. The example below expects reconstructed particles together with their
points and depositions products. Save this minimal configuration as
inspect.yaml:
base:
iterations: -1
io:
reader:
name: hdf5
file_keys: /path/to/spine_output.h5
keep_open: false
build:
mode: reco
units: cm
fragments: false
particles: true
interactions: false
Load one entry, rebuild the long-form particle representation, and draw it:
from spine.config import load_config_file
from spine.driver import Driver
from spine.vis import Drawer
cfg = load_config_file("inspect.yaml")
data = Driver(cfg).process(entry=0)
drawer = Drawer(data, draw_mode="reco")
fig = drawer.get("particles")
fig.show()
The build block is important: the HDF5 reader restores the serialized
particle records, while the builder reconnects their point, deposition, and
index data for downstream consumers such as spine.vis.Drawer.
For model training and inference, run SPINE from the released container with a compatible LArCV input file and configuration:
# Using the newest published image
docker run --gpus all -v $(pwd):/workspace \
ghcr.io/deeplearnphysics/spine:latest \
spine --config /workspace/config/full_chain/full_chain_regression.yaml \
--source /workspace/input.root
# Or use a pinned release image
docker run --gpus all -v $(pwd):/workspace \
ghcr.io/deeplearnphysics/spine:<release> \
spine --config /workspace/config/full_chain/full_chain_regression.yaml \
--source /workspace/input.root
On Apple Silicon macOS systems, pass --platform=linux/amd64 to docker
run when using the published SPINE image. For Jupyter notebook/lab use,
avoid the Docker Desktop combination of Apple Virtualization Framework with
Rosetta enabled; Apple Virtualization Framework without Rosetta and Docker VMM
have both been verified to work.
For the full interactive-container workflow, Apptainer examples, and the longer Python walkthrough, see Quick Start.
SPINE also exposes lower-level modules for data structures, model components, construction, analysis, math helpers, and visualization, but the main user-facing workflow starts from the driver and configuration system.
